SPECIFICATIONS
ENGINE
Engine Type
197cc, Air Cooled, 4-stroke, single cylinder, Manual transmission
Start Type
Electric Start
Transmission
Chain Drive
Engine Gear
4-3-2-1-N-R
Shift Gear
Foot
Max Torque
8.5N.m/5000-5500r/min
Wheelbase
43.9 inches
Ignition
CDI
Fuel Tank Capacity
1.1 Gallons
CHASSIS
Front Hand Brake
Drum
Rear Foot Brake
Hydraulic Disc
Tire Front
23×7-10
Tire Rear
22×10-10
Front Suspension
15.7 inches
Rear Suspension
13.4 inches
Remote Control
No
Speed Limiter
Yes
Engine kill switch
Yes
DIMENSION
Battery
12V/9Ah
G.W
363.76 LBS
N.W
308.65 LBS
Max Loading
198 LBS
Overall Size
69.3 x 42.1 x 43.3 inches
Carton Size
55.9 x 33.0 x 34.3 inches
Seat Height
31.89 inches
Ground Clearance
5.32 inches
